16Mo3 Pipe belongs to EN10028 specification. It is a pressure vessel grade steel that could be used under high temperature and pressure. There are different standards and schedules of these chromium molybdenum alloy pipes. The NFA 36–205 16Mo3 Seamless Pipe has a thickness ranging from 4m to 350mm depending on the diameter of the pipe and the pressure classes. There are other classes that are applied for very high temperatures such as the 16Mo3 1.5415 Boiler Pipe which is used primarily in boilers. There are pipes that could be used with high precision in high sensitivity applications such as the 1.5415 16Mo3 Steel Seamless Pipe. Since these seamless pipes have less absolute roughness, they are easy to install with minimal use of tools and can create better sealing at connections.

Tianjin Bao Steel Pipe CO.,LTD is a professional and experienced steel pipe supplier and exporter, the largest distributor of TPCO, Baosteel Group and Angang Group, exporting more than 150,000 tons of steel pipes and fittings to more than 150 countries every year. We have a large stock of 16Mo3 steel pipes of various grades, which can be shipped promptly after you place an order. We also have perfect pipe deep processing capabilities, such as pipe 3PE coating, aluminizing, thermal expansion, U-shape processing, threading, slotting, finning, etc. If you need, welcome to inquire.

Specification

Technical data

Chemical composition% of steel 16Mo3 (1.5415): EN 10028-2-2003

C	Si	Mn	Ni	P	S	Cr	Mo	N	Cu
0.12 - 0.2	max 0.35	0.4 - 0.9	max 0.3	max 0.025	max 0.01	max 0.3	0.25 - 0.35	max 0.012	max 0.3

Mechanical properties of steel 16Mo3 (1.5415)

Nominal thickness (mm):	to 60	60 - 100	100 - 150	150 - 250
Rm - Tensile strength (MPa) (+N)	440-590	430-580	420-570	410-570

Nominal thickness (mm):	to 250	250 - 500
Rm - Tensile strength (MPa) (+QT)	440-570	420-550

Nominal thickness (mm):	to 16	16 - 40	40 - 60	60 - 100	100 - 150	150 - 250
ReH - Minimum yield strength (MPa) (+N)	275	270	260	240	220	210

Nominal thickness (mm):	to 250	250 - 500
ReH - Minimum yield strength (MPa) (+QT)	265	250

FAQ

1.Q: Are you a factory or trading company?
A: We are professional manufacturer, and our company also is a very professional a trade company for steel products.We can provide a wide range of steel products.

2.Q:What do your factory do regarding quality control?
A: We have obtained ISO, CE and other certifications. From materials to products, we check every process to maintain good quality.

3.Q: Can I get samples before order ?
A: Yes, of course. Usually our samples are free. we can produce by your samples or technical drawings.

4.Q:How do you make our business long-term and good relationship?
A:We keep good quality and competitive price to ensure our customers benefit ; We respect every customer as our friend and we sincerely do business and make friends with them.No matter where they come from.

5.Q:what is your delivery time ?
A: Our delivery time is about one week, timing according to the number of customers.
