API 5CT Grade L80 Casing Pipe

API 5CT Grade L80 Casing Pipe

API 5CT Grade L80 Casing Pipe

API 5CT Grade L80 Casing Pipe

API 5CT Grade L80 Casing Pipe

API 5CT Grade L80 Casing Pipe

API 5CT Grade L80 Casing Pipe

API 5CT Grade L80 Casing Pipe

API 5CT Grade L80 Casing Pipe

Specification:

API 5CT/ISO 11960

Material:

L80, steel grade

Outer Diameter:

4 1/2″-20″, (114.3-508mm)

Wall Thickness:

1.0mm – 30 mm

Casing Dimensions:

114.3 mm (4.5″) to 406.4 mm (16″)

Tubing Dimensions:

26.7 mm (1.05″) to 114.3 mm (4.5″)

Share:

Introduction

Specification

Projects

Qualification

Introduction

API specification 5CT is a technical standard for tubes and pipes in a system intended for use in oil wells in petroleum as well as in natural gas industries. Unlike API 5L, the API 5CT Grade L80 Pipes are classified into three product specification levels, i.e. - PSL-1, PSL-2, and PSL-3. Pipes that belong to grade L80 are heat treated after being upset. Per this standard, different grades will vary in their heat treatment processes.

Tianjin Bao Steel Pipe CO.,LTD is a professional and experienced steel pipe supplier and exporter, the largest distributor of TPCO, Baosteel Group and Angang Group, exporting more than 150,000 tons of steel pipes and fittings to more than 150 countries every year. We have a large stock of API 5CT Grade L80 Casing Pipe of various grades, which can be shipped promptly after you place an order. We also have perfect pipe deep processing capabilities, such as pipe 3PE coating, aluminizing, thermal expansion, U-shape processing, threading, slotting, finning, etc. If you need, welcome to inquire.

Quality Inspection

Quality Inspection

Quality Inspection

Specification

Product Details

Composition Standard of API-5CT L80 Casing Pipe

Grade	C≤	Si≤	Mn≤	P≤	S≤	Cr≤	Ni≤	Cu≤	Als≤
API 5CT L80	0.15-0.22	1.00	0.25-1.00	0.020	0.010	12.0-14.0	0.20	0.20	0.020

Carbon Steel API 5CT GR. L80 Pipes Mechanical Analysis

Steel Grade	Yield Strength (Mpa)	Tensile Strength (Mpa)
API 5CT L80	552-655	≥655

API 5CT GR.L80 Pipe Dimension Tolerance

Types of steel tubes	Outer Diameter		Wall Thickness
Cold-rolled tubes	Tube sizes(mm)	Tolerances(mm)	Tolerances(mm)
	＜114.3	±0.79	－12.5％
